Toreleasetheplatformandswingitoutorin,pressuponthe

frontplatformlatch(Figure11).

Figure11

1.Frontplatformlatch

ControlPanel

g028900

10

1

2

3

4

5

6

7

8

9

Figure12

1.Engine-stopbutton

6.Ground-strike-resetswitch

2.Exit-sidelockout—reset

light

7.Exit-side-lockout—reset

switch

3.Exit-side

lockout—drill-enabled

light

8.Drive/drillswitch

4.Receiver-battery-status

light

9.Lightsswitch

5.Engine-startbutton10.Engine-speedswitch

Exit-SideLockout—ResetLight

Thislight(Figure12)illuminatesyellowwhentheexit-side

lockoutfunctionisturnedoffonexit-side-lockouttransmitter,

indicatingthatyoumayresetthesystem.

Exit-SideLockout—Drill-enabledLight

Thislight(Figure12)illuminatesgreenwhenthe

exit-side-lockoutfeaturehasbeenturnedoffandresetand

themachineisreadytodrill.

Exit-SideLockout—ResetSwitch

Pressthisswitch(Figure12)toenabledrillingoperationwhen

theresetlightilluminates.

Transmitter-Battery—StatusLight

Thislight(Figure12)illuminatesredwhenthebatteryon

theexit-side-lockouttransmitteristoolowtotransmit.Stop

drillingoperationsandxtheproblemwiththetransmitter

beforecontinuing.

Engine-StartButton

Pressthisbutton(Figure12)tostarttheengine.Thekey

switchontherear,controlpanelmustbeintheONposition.

Engine-StopButton

Pressthisbutton(Figure12)toimmediatelystoptheengine

andalldrillingoperations.Youmustpullthisbuttonout

beforeyoucanstarttheengineagain.

Ground-Strike-ResetSwitch

Pressthisswitch(Figure12)toresettheZap-Alertsystem

afteragroundstrikehasoccurredandbeenxed;referto

DeployingtheZap-AlertSystem(page46).

Drive/DrillSwitch

Pressthetopofthisswitch(Figure12)toenablethedriveand

setupcontrolsorthebottomtoenabledrillandpipe-loader

functions.

LightsSwitch

Pressthetopofthisswitch(Figure12)toturnthemachine

lightsonorthebottomtoturnthemoff.

Engine-SpeedSwitch

•Pressandholdthetopofthisswitchtoincreasethe

enginespeed.

•Pressandholdthebottomofthisswitchtodecreasethe

enginespeed.

•Releasetheswitchtomaintainthecurrentenginespeed.

22
