Operational Information
Working on circular saws
Cutting wide workpieces, Fig. 24
Width of the workpiece to be machined over 120 mm
Operating cycle: Adjust the ripping fence in accordance
with the width of the workpiece. Ensure that your hands
are resting in a safe place. The workpiece may only be
forward-fed in the tool area with the right hand or with
the aid of a push-stick if narrow workpieces are cut off in
the cutting process. Move the fence back to the middle
of the saw or use a short auxiliary fence if there is a dan-
ger of the workpiece being jammed between the circular
sawblade, the riving knife and the fence.
Only the upper suction hood has been left out in the in-
dividual case in order to display the operating cycle or
device more clearly.
The upper suction hood is required for all of the opera-
ting cycles.
Cutting narrow workpieces, Fig. 25
Be sure to use a push stick when making longitudinal
cuts in workpieces smaller than 120 mm in width. A push
block is supplied with the saw! Replace a worn or dam-
aged push stick immediately.
• Adjust the parallel stop to the width of workpiece you
require.
• Feed in the workpiece with two hands. Always use the
push stick in the area of the saw blade.
• Always push the workpiece through to the end of the
splitter.
m Caution! With short workpieces, use the push stick
from the beginning.
Cutting edges and strips, Fig. 26
Operating cycle: Mount the fence with a low stop bar
surface or use an auxiliary fence. Feed the workpiece
with a push-stick until the end of the workpiece is in the
region of the riving knife. Prevent long workpieces from
toppling over at the end of the cutting process by using a
table length extension.
Making cross cuts, Fig. 27
Operating cycle: Adjust the rejection rail so that work-
piece sections do not touch the ascending part of the
sawblade. Only feed the workpiece by means of a cross-
feed stop or a cross slide.
Do not remove wood chippings from the region of the
workpiece with your hands.
Maintenance
m Warning! Prior to any adjustment, maintenance or
service work disconnect the mains power plug!
General maintenance measures
• Keep all safety devices, air vents and the motor hous-
ing free of dirt and dust as far as possible. Wipe the
equipment with a clean cloth or blow it down with com-
pressed air at low pressure.
• We recommend that you clean the equipment imme-
diately after you use it.
• Clean the equipment regularly with a damp cloth and
some soft soap. Do not use cleaning agents or sol-
vents; these may be aggressive to the plastic parts in
the equipment. Ensure that no water can get into the
interior of the equipment.
Operation
Working instructions
After each new adjustment it is advisable to carry out a
trial cut in order to check the set dimensions. After switch-
ing on the saw, wait for the blade to reach its maximum
speed of rotation before commencing with the cut.
Secure long workpieces against falling off at the end of
the cut (e.g. with a roller stand etc.)
Take extra care when starting the cut!
Never use the equipment without the suction function.
Regularly check and clean the suction channels.
Make sure, that you select a saw blade that is appropri-
ate for the material you intend to cut.
Connect the power tool to a dust reception facility when
cutting wood.
Do not use saw blades made out of high-speed steel
(HSS steel).
Use the push stick or the feed lever for sliding the wood,
to guide it safely past the saw blade. In times of non-use
keep the push stick or the push block with the electrical
power tool at all times.
Saw Blade – Diagonal Adjustment
• The saw blade may be swiveled from 90° to 45° after
the wing nut has been loosened.
After each new adjustment it is advisable to carry
out a trial cut in order to check the set dimensions.
Readjust the angle adjustment on the adjusting bolts 1
& 2.
Saw Blade Height Adjustment
The saw blade is adjustable from 0 to 83 mm cutting
height after the wing nut has been loosened.
For safe and clean working, choose a minimal saw
blade projection for the workpiece.
Dem Spaltkeil wie im Bild 22 gezeigt einstellen.
Adjust the riving knife as shown in picture 22.
The riving knife is an important safety device which guides
the workpiece and prevents the cutting joint from closing
behind the saw blade and the workpiece from being ki-
cked backwards. Check the riving knife thickness. The
riving knife should never be thinner than the body of the
saw blade or thicker than the cutting joint width.
Only use saw blades with a diameter of 315 mm and a
thickness of 2.4 mm (3.0 mm teeth).
Lower the suction hood onto the workpiece during every
working cycle. The hood must be positioned horizontally
above the saw blade during every working cycle.
Length Cuts
Insert the length stop for parallel cuts.
Use the stop ruler with the high stop side for cuts above
120 mm and the stop ruler with the low stop side for cut
widths under 120 mm.
Lead the workpiece with the push stick.
Diagonal Cuts
For diagonal and angle cuts, insert the cross-cutting
guide.
