WEH200/WEH300
V. 07 – 24/06/2021 13 ©Velleman nv
The appliance is statically
charged.
Earthed error or no
connection to earth.
Checked earthed wires and
properly connect them.
The internal connectors are
touching the housing.
Check all internal
connections.
End-switch is not functioning.
The end-switch is defect.
Switch off or change.
The end-switch is blocked.
Check, repair, and change
end switch.
10. Technical Specifications
WEH200
power supply ...................................................................................... max. 230 V~, 50 Hz
power consumption ................................................................................................1000 W
single-hook configuration
max. load capacity ............................................................................................. 200 kg
lifting height ....................................................................................................... 12 m
lifting speed .................................................................................................. 8 m/min.
double-hook configuration
max. load capacity ............................................................................................. 400 kg
lifting height ......................................................................................................... 6 m
lifting speed .................................................................................................. 4 m/min.
cable dimensions ....................................................................................... Ø 4 mm x 12 m
sound pressure level (LWA) .................................................................................. 71 dB(A)
WEH300
power supply ...................................................................................... max. 230 V~, 50 Hz
power consumption ................................................................................................1050 W
single-hook configuration
max. load capacity ............................................................................................. 300 kg
lifting height ....................................................................................................... 12 m
lifting speed .................................................................................................. 8 m/min.
double-hook configuration
max. load capacity ............................................................................................. 600 kg
lifting height ......................................................................................................... 6 m
lifting speed .................................................................................................. 4 m/min.
cable dimensions .................................................................................... Ø 4.5 mm x 12 m
sound pressure level (LWA) .................................................................................. 71 dB(A)
Use this device with original accessories only. Velleman nv cannot be held
responsible in the event of damage or injury resulting from (incorrect) use of this
device. For more info concerning this product and the latest version of this manual,
please visit our website www.velleman.eu. The information in this manual is subject
to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved.
No part of this manual may be copied, reproduced, translated or reduced to any electronic
medium or otherwise without the prior written consent of the copyright holder.
