WEH200/WEH300
V. 07 – 24/06/2021 11 ©Velleman nv
Intermittent Rating
This appliance is designed for operating type S3 20 % - 10 min. (periodic intermittent
operation). The relative duty cycle is 20 %, which means that the appliance can be operated at
rated load for 2.0 minutes during each operating cycle and must then be switched off for 8
minutes to cool off. The appliance can therefore be continuously used for a duration of 20 % of
the total operating cycle of 10 minutes at rated load.
Overload
• The appliance is not suitable for continuous operation. The motor is protected from
overload and overheating by a temperature switch.
• If the permissible operating time is exceeded, the motor temperature will increase and the
temperature switch will shut the appliance off. The temperature switch will automatically
switch
back on after a cooling phase.
• In case of a strain on the appliance with a lesser load, the operating time will increase and
the cooling time will decrease.
• In case of direct exposure to sunlight, the temperature of the casing will increase
significantly, which will also decrease the permissible operating time. It is therefore
possible that the temperature switch will switch off after a short period and the appliance
will shut down. Please wait until the device is cooled off.
8. Care and Maintenance
WARNING
• Always disconnect the appliance from the mains before starting any cleaning, maintenance
or servicing work.
• In the following: One cycle means one raising and lowering movement of a load. Periodic
inspection means an inspection after 100 cycles.
Cleaning
• Keep all safety devices, air vents and the motor housing free of dirt and dust.
• Wipe the appliance with a clean cloth or blow it with compressed air at low pressure. Clean
the appliance regularly with a moist cloth and some soft soap. Do not use cleaning agents
or solvents as these could attack the plastic parts of the appliance. Ensure that no water
can seep into the appliance.
• We recommend that you clean the appliance immediately after each use.
Maintenance
• A check must be made every 30 cycles to find whether the entire steel cable is in good
condition. If it is damaged (split or bent, see illustration below), it must be replaced by a
steel cable of the type specified in the technical data.
• Check that the power supply cable, motor stop switch and the push button are in good
working condition.
Servicing
• Periodically test that the limit switches on the cable hoist are in correct working order.
Conduct this test as follows: when the cable has reached the maximum height, the lever on
the automatic stopping mechanism will be actuated. The motor must then stop (test
without a load).
