11 Troubleshooting

Problem Possible cause Suggested solution

Error Calculation failed Repeat the measurements.

204 Calculation error Repeat the measurement.

208 Excessive current The device failed. Contact a specialist.

220 Low battery Replace the batteries or charge the rechargeable

batteries.

255 The received signal is

weak.

Measuring time is too

long.

Select measuring points on the target surface of

a different material to improve the signal reflec-

tion.

256 The received signal is too

strong.

Select measuring points on the target surface of

a different material to reduce the signal reflec-

tion.

261 The measurement dis-

tance is out of range.

Ensure the distances you measure are within the

range of the device.

500 Hardware error Switch the product on and off several times. If

the problem persists, contact a specialist.

12 Cleaning

Important:

– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.

They damage the housing and can cause the product to malfunction.

– Do not immerse the product in water.

1. Switch the product off.

2. Clean the product with a dry, fibre-free cloth.

3. Store the product in the pouch.

13 Disposal

13.1 Product

This symbol must appear on any electrical and electronic equipment placed on

the EU market. This symbol indicates that this device should not be disposed of

as unsorted municipal waste at the end of its service life.

Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose

of it separately from unsorted municipal waste. Spent batteries and accumulators,

which are not enclosed by the WEEE, as well as lamps that can be removed from

the WEEE in a non-destructive manner, must be removed by end users from the

WEEE in a non-destructive manner before it is handed over to a collection point.

Distributors of electrical and electronic equipment are legally obliged to provide free take-

back of waste. Conrad provides the following return options free of charge (more details on

our website):

■

in our Conrad offices

■

at the Conrad collection points

■

at the collection points of public waste management authorities or the collection points

set up by manufacturers or distributors within the meaning of the ElektroG

End users are responsible for deleting personal data from the WEEE to be disposed of.

It should be noted that different obligations about the return or recycling of WEEE may apply

in countries outside of Germany.

13.2 (Rechargeable) batteries

Remove batteries/rechargeable batteries, if any, and dispose of them separately from the

product. According to the Battery Directive, end users are legally obliged to return all spent

batteries/rechargeable batteries; they must not be disposed of in the normal household

waste.

Batteries/rechargeable batteries containing hazardous substances are labelled

with this symbol to indicate that disposal in household waste is forbidden. The ab-

breviations for heavy metals in batteries are: Cd = Cadmium, Hg = Mercury,

Pb = Lead (name on (rechargeable) batteries, e.g. below the trash icon on the

left).

Used (rechargeable) batteries can be returned to collection points in your municipality, our

stores or wherever (rechargeable) batteries are sold. You thus fulfil your statutory obligations

and contribute to environmental protection.

Batteries/rechargeable batteries that are disposed of should be protected against short cir-

cuit and their exposed terminals should be covered completely with insulating tape before

disposal. Even empty batteries/rechargeable batteries can contain residual energy that may

cause them to swell, burst, catch fire or explode in the event of a short circuit.

14 Technical data

Power supply.................................. 2 x AAA batteries or 2x NiMH AAA rechargeable

batteries

Battery life....................................... Max. 3500 measurements

Charging time ................................. 4 – 4.5 h (for rechargeable batteries)

Data memory.................................. 50 measurements

Measuring range............................. Item no.: 3208201: 0.2 – 40 m

Item no.: 3208202: 0.2 – 60 m

Measuring accuracy ....................... ± 2.0 mm

Angle measurement accuracy........ ± 0.3°

Laser class ..................................... Class 2

Laser wavelength ........................... 630 – 670 nm

Laser output power......................... <1 mW

Response time................................ <0.5 s

Ingress protection........................... IP65

Tripod mount .................................. 6.35 mm (1/4”)

Operating temperature ................... -10 to +40 °C

Storage temperature....................... -20 to +60 °C

Dimensions (L x W x H).................. 120 x 55 x 25 mm

Weight ............................................ 151 g (including batteries)

Accuracy

Measurement errors are influenced by temperature, with a deviation (D) ranging from -0.1°

to +0.1°. For example, under normal temperature conditions, the accuracy is ±0.3° at an

angle of 0°. At higher temperatures, the accuracy decreases to ±0.85° at an angle of 45°.

Laser label

This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).

All rights including translation reserved. Reproduction by any method (e.g. photocopying, microfilming or the capture in

electronic data processing systems) requires prior written approval from the editor. Reprinting, also in part, is prohibited.

This publication reflects the technical status at the time of printing.

Copyright by Conrad Electronic SE.

*3208201 3208202_V2_0125_jh_mh_en 18014400096998539-2 I3/O2 en
