TOA Electronics Europe GmbH 1
d Instruction Manual
SWITCH-OVER BOX
SOB-1
■ DESCRIPTION
The switch-over box can be used to switch over
a local PA to a central PA system, or to supply a
line level signal into a local PA amplifier with
priority. 4 switch over contacts are available for
priority control and switching over speakers. A
low impedance speaker can be connected to a
100 volts line via a build-in 5 watts transformer.
■ SCHEMATICS ■ PCB LAYOUT
■ SPECIFICATIONS
Audio Input 100 V AC, max. 5W
Audio Output 5 W into 4 ohms
100 mV ... 2V into 10 kohms (adjustable)
Switching Load Relays 100W (100 V AC, 1A)
Relay Voltage 24 V DC, 16 mA
Dimensions (H x W x D) 60 x 100 x 100 mm (without cable inlet)
60 x 100 x 123 mm (with cable inlet)
SOB-1 P1.0
manufactured for
TOA Electronics Europe GmbH
H C
OUT
AF
6
100V
H
1
JP1
C
1
1 2 3 4 5
IN
D3
JP2
dir.
100V
H C
7 8 9 10 11
RY1
D1
R3
4
3
20
Ω
4OUT
1
2
1
2
JP3
3
4
R1
R2
H
H C
dir.
4
Ω
JP4
C
1812 13 14 15 16 17 19
RY2
D2
C1
JP4
D2
1N4148
Ω
CN1
9
10
8
7
6
3
2
1
5
4
4
D3
RY1
1N4148
1N4148
D1
100V 5W
JP2
JP1
T1
1
2
3
1
2
3
11
20
19
18
16
17
15
14
13
12
33nF
47
JP3
1
2
3
4
3
4
1
2
RY2
R2
1.2 k
R1
R3
100
C1
CN2
VR1 1k
