6 SPECIFICATIONS
Notes
• The design and speci cations are subject to change without notice for improvement.
• The speci cations data was measured in an anechoic chamber, according to EN 54-24.
• Reference axis: Axis is on the center of horn-mouth and perpendicular to the horn-mouth.
• Reference plane: Plane is on the horn-mouth and perpendicular to the reference axis.
• Horizontal plane: Plane is containing the reference axis and perpendicular to the reference plane.
Standards
Certi ed to the European Standard EN 54-24:2008
Loudspeaker for voice alarm systems for re detection and re alarm systems
Certi cation No. 1438-CPR-0280
Environment Type Type B (Outdoor applications)
Rated Noise Power 30 W (100 V line and 70 V line)
Rated Impedance
100 V line: 330 (30 W), 670 (15 W), 1 k (10 W), 2 k (5 W)
70 V line: 170 (30 W), 330 (15 W), 670 (7.5 W), 1 k (5 W), 2 k (2.5 W)
Sensitivity
113 dB (1 W, 1 m at 500 Hz to 2.5 kHz peak level)
99 dB (1 W, 1 m at 100 Hz to 10 kHz pink noise)
87 dB (1 W, 4 m at 100 Hz to 10 kHz pink noise)
Max.SPL
111 dB (30 W, 1 m at 100 Hz to 10 kHz pink noise)
99 dB (30 W, 4 m at 100 Hz to 10 kHz pink noise)
Frequency Response 250 Hz – 10 kHz
Coverage Angle (–6 dB)
Horizontal: 360° (500 Hz), 115° (1 kHz), 73° (2 kHz), 33° (4 kHz)
Vertical: 360° (500 Hz), 86° (1 kHz), 53° (2 kHz), 32° (4 kHz)
Operating Temperature –20 ºC to +55 ºC
Dust/Water Protection* IP65
Cable Polarity Hot: Black, Com: White
Finish
Horn are: Aluminum, off-white, powder coating
Re ector horn, Trans case: ABS resin, off-white
Bracket, screws and bolts: Stainless steel
Dimensions 285 (w) x 227 (h) x 277 (d) mm
Weight 2 kg
• Optional products
Svivel Bracket: YS-151S (Can be used instead of the supplied bracket.)
Junction Box according to EN 60670 (mandatory for cable conection in accordance with EN 54-24:2008)
*Remark: The required protection grade under EN 54-24 standard is IP 33C and is certi ed from noti ed body
CNBOP accordingly.
