33
Timer
[Example]
Connecting a timer to Control Input Terminal 1
Note:
This figure represents the VM-3240VA/3360VA.
Control input terminals
Control output terminals
[VM-3240VA/3360VA/3240E/3360E]
Over 100 ms
At the same time, a set contact is output from the control output terminal if interlock outputs have also
beenset.(Forinterlockoutputsettings,referto"GeneralControlInputSettings"in"EventSettings"in
the separate software instruction manual.)
Step 3. After the automatic general announcement playback is complete, the broadcast is terminated and the
indicator goes out.
Makesettingssothattheautomaticgeneralannouncementisbroadcastoverthedesignatedzone(s)when
the control input terminals of the VM-3240VA, VM-3360VA, VM-3240E or VM-3360E are activated.
(For more information, refer to "VM-3000VA Settings" or "VM-3000E Settings" in "System Settings" in the
separate software instruction manual.)
All-zone call indicator Output indicator
[VM-3240VA/3360VA]
5.3. Making Automatic Announcements Using Control Signal Inputs
This function makes general broadcasts by playing back internal automatic announcements activated when
the control input terminals located on the rear panel of the VM-3240VA, VM-3360VA, VM-3240E or VM-3360E
receive a broadcast control signal.
Performthefollowingsettingsinadvanceusingthesettingsoftware:
Step 1. Connectatimerorotherexternalcontroldevicetothecontrolinputterminalslocatedontherearpanel
of the VM-3240VA, VM-3360VA, VM-3240E or VM-3360E.
Step 2. When the timer’spreset time is reached, the Contact Input receives acontact output signal (make
contact)fromthetimer.Theall-zonecallindicatororoutputindicatorcorrespondingtothesetzone
lightsgreenandtheautomaticgeneralannouncementisbroadcastoverthatzone.
