30
[Making microphone announcements by activating control inputs]
Performthefollowingsettingsinadvanceusingthesettingsoftware:
Step 1. Close ("Make") the Control Input terminals on the rear panel of the VM-3240VA or VM-3360VA.
In this event, if interlock outputs have been set, a set contact is provided from the Control Output
terminal.(Forinterlockoutputsettings,referto"GeneralControlInputSettings"in"EventSettings"in
the separate software instruction manual.)
Step 2. Make a microphone announcement using the microphone connected to the audio input terminal on the
rear panel.
Step 3. To terminate the microphone announcement, open ("break") the Control Input terminals. The
corresponding indicator goes out, terminating the microphone announcement.
Thecorrespondingall-zonecalloroutputindicatorlightsgreen,allowingmicrophoneannouncements
to be broadcast from the corresponding speaker line.
All-zone call indicator Output indicator
[VM-3240VA/3360VA]
Microphone talk switch
[Example]
Setting microphone announcement activation for Control
Input Terminal 1.
Control Input terminals
Control Output terminals
[VM-3240VA/3360VA]
• Setthepriorityleveloftheaudioinputterminaltowhichthemicrophoneisconnectedtoanyof"1"–"6".
(Refer to "General Broadcast Priorities" on p. 48 for priority levels, and to "Priority Settings" in the
separate software manual for how to set priorities.)
• Performsettings sothat amicrophone announcement isbroadcast overdesignatedbroadcast zones
when the control input terminal is activated. (For more information, refer to "General Control Input
Settings" in "Event Settings" in the separate software instruction manual.)
