5
4. SYSTEM EXAMPLE
4.1. SIP Broadcasting/Two-way Communication
SIP phone conversations possible using a microphone and a speaker connected to the unit.
SIP phone
or
SIP intercom
LAN
SIP server
SIP broadcasting
Speaker output
High-impedance speaker
Microphone panel
Microphone input
Control input
SIP audio from microphone
IP-A1PA12
Tips
• Set the local broadcasting settings "OFF." If it is "ON," the microphone input voice will not be output
as SIP call from microphone.
• When the voice switch setting is "ON," the call will be half-duplex.
LAN
VMS
software
VMS broadcasting
Speaker output
High-impedance speaker
Microphone input
Microphone for sound collection
Monitoring with audio
IP-A1PA12
4.2. VMS Broadcast System
VMS software broadcasts can be performed to speakers connected with the unit. An external
microphone can also be connected for monitoring audio in the eld.
Tip
Set the local broadcasting settings "OFF." If it is "ON," the microphone input voice will not be output
as monitoring audio.
Audio from the unit
High-impedance speaker
Audio from an external amplifier
IP-A1PA12
External
Amplifier
Control input
4.3. Linked External Amplier Broadcast System
The speaker line connected to this unit can be shared with an external amplier for broadcasting from
the external amplier.
By connecting a speaker line and control signal of existing PA system to this unit, it is possible to
build a system that combines an analog PA system and a network PA system.
