4
2. SUMMARY AND FEATURES
The IP-A1PA12 is an IP Power Amplier which decodes IP audio streams into analog signals.
It is equipped with a built-in 12 W amplier to drive High-impedance speaker(s).
Analog audio and control outputs can be connected to an external amplier for scaling up the system
capability.
• Power is supplied by way of PoE+ (IEEE 802.3at) switching hubs.
• The IP Power Amplier is compatible with the following broadcasting modes:
Internal sound source
broadcasting mode
Enables broadcast of up to 20 internal sound source les by means of
control input or Remote API (HTTP/HTTPS).
VMS broadcasting
mode
Enables backchannel audio broadcast from the VMS (Video
management system) software using the common protocol for IP
cameras.
SIP broadcasting mode Enables SIP broadcasts from any voice communications device that
utilizes the SIP protocol, such as SIP or IP telephone (IP-PBX) systems.
Multicast broadcasting
mode
Allows up to 20 multicast ports to be set up, for 20 multicast audio
stream paging groups.
Local broadcasting
mode
Local broadcasting mode enables broadcast locally to the speaker
output from the sound source device or microphone connected with
LINE/MIC input.
• Orders of priority can be set among the various broadcasting modes, meaning higher priority
broadcasts can interrupt and override lower priority broadcasts.
• Since the unit is equipped with individual oset adjustable volumes for each broadcasting modes
and patterns (internal sound source), actual broadcasting volume can be normalized or optimized.
• Broadcasts can be controlled using Remote API or control inputs from connected external
equipment.
• Connected external equipment can be controlled by control outputs in synchronization with speaker
broadcasts.
• This unit can be connected to an external amplier and can broadcast from an external amplier
to a speaker line connected to this unit. It is possible to build a system that can broadcast from the
network by sharing a speaker line of an existing PA system.
3. ABOUT SECURITY MEASURES
• Ensure that sucient security measures are taken on the customer’s own responsibility.
• TOA Corporation takes no responsibility for damage or loss caused by security-related problems,
such as illegal access.
• To help prevent illegal access to the unit, be sure to change the user ID and password from those
used for initial setup. For setting methods and other details, please refer to the separate receiving
device setup manual which can be downloaded from the TOA DATA Library (https://www.toa-
products.com/international/).
• Take utmost care in the management of the unit’s communications password.
This equipment is not suitable for use in locations where children may be present.
Warning: Operation of this equipment in a residential environment could cause radio
interference.
