materialdamageandpossiblepersonalinjury.
• Tighten each nut and bolt securely. Ensure that
the bracket has no loose joints after installation
to prevent accidents that could result in personal
injury.
• Use the HX-7B or HY-7W Speaker System in
combination. Doing otherwise may cause the
speaker or component to fall off, resulting in
personalinjury.
• Do not mount the speaker in locations exposed
to constant vibration. The mounting bracket can
be damaged by excessive vibration, potentially
causing the speaker to fall, which could result in
personalinjury.
• Avoid installing the speaker in locations such
as in indoor swimming facilities that are not well
ventilated. In such locations, the bracket may be
vulnerable to corrosion, eventually allowing the
speakertofallresultinginpersonalinjury.
• Avoid touching the bracket’s sharp metal edge to
preventinjury.
• Donotplaceheavyobjectsonthespeakerasthis
may cause it to fall or break which may result in
personalinjuryand/orpropertydamage.Inaddition,
theobjectitselfmayfalloffandcauseinjuryand/or
damage.
• Do not stand or sit on, nor hang down from the
bracketasthismaycausethespeakertofalldown
ordrop,resultinginpersonalinjuryand/orproperty
damage.
• Havethebracketcheckedperiodicallybytheshop
fromwhereitwaspurchased.Failuretodosomay
result in corrosion or damage to the bracket that
could cause the speaker to fall, possibly causing
personalinjury.
Indicatesapotentiallyhazardoussituationwhich,
ifmishandled,couldresultinmoderateorminor
personalinjury,and/orpropertydamage.
CAUTION
2. GENERAL DESCRIPTION
TheHY-VM7SeriesSpeakerRiggingBracketsareusedtoconnecttheHX-7BorHX-7WSpeakerSystemto
theoptionalHY-WM7BorHY-WM7WSpeakerWallMountingBracketsorHY-C0801orHY-C0801WSpeaker
CeilingMountingBrackets.Itisalsopossibletosuspendthespeakersystemfromtheceilingormountittothe
ceilingorbeamswiththeuseoftheHY-VM7bracket.
3. MOUNTING THE SPEAKER ON A WALL
(using the optional HY-WM7B or HY-WM7W bracket)
Mount asingle HX-7Bor HX-7W SpeakerSystem tothe wallbyusingtheHY-VM7 incombination with the
optionalHY-WM7BorHY-WM7Wbracket.
3.1. Mounting Diagrams
[Component disassembly] [Completed installation]
HY-WM7B or HY-WM7W
Speaker Wall Mounting Bracket
This bracket (T-bracket)
This bracket (Angle bracket)
HX-7B or HX-7W
This bracket (Mounting base)
Note
OnlyoneHX-7BorHX-7Wspeakercanbemounted.
Twojoinedspeakerscannotbemounted.
