4. INSTALLATION
Step 1. Setthedesiredspeakerdirectivityanglemodeasneeded.
Formodesetting,refertotheinstructionmanualsuppliedwiththeHX-7BorHX-7W.
Notes
• Ifsetto60°mode,thespeakercannotbemountedonthespeakerstandwiththeHY-ST7.
• Whenmountingthespeaker,setallrearanglebarstothesamedirectivityanglemodeposition.
Step 2. Attachthemountingadapter(recommendedproduct:K&M’s19580)tothemountingbase.
Settheadapter’sboltxingpositionsothattheboltisinsertedthroughtheedgeofeachmountinghole
oftheadapter,asshowninthegurebelow.Also,tightentheboltsusingthestandadaptermounting
holescorrespondingtothespeakerdirectivityanglemode,asshowninthegure.
Flange nut for M8 (accessory)
[Stand adapter mounting hole]
Hex head bolt M8 x 20
with spring and plain washers (accessory)
Mounting adapter (Commercial product)
0
0
5
5
1
3
4
When set to 0º mode or 15º mode
When set to 30º mode or 45º mode
Tightening torque: 8 N·m
Tighten the bolts securely, as instructed below. Failure to follow
instructions precisely could result in a falling speaker and potential
personal injury.
• Ensurethatallboltsaresecurelyinsertedasfarastheirthreadsgo,
then securely fasten each bolt with a nut.
• Tighten all the bolts with the designated tightening torque. For
tightening,useaPhillipsscrewdriver,oropen-orbox-endwrench.
WArNING
