HY-CN7B, HY-CN7W, HY-CN7B-WP and HY-CN7W-WP Speaker Connection Brackets
HX-7 Series speaker
Side angle plate of Speaker
Connection Bracket
Rear angle bar of Speaker
Connection Bracket
Use the brackets to join.
First speaker
Second speaker
Protection cover Speaker molule A Speaker molule B
3. cOMPLETE ASSEMbLY
(Joined speaker example using two HX-7 Series Speaker Systems)
4. JOINING TWO SPEAKER SYSTEMS
Be sure to observe the following precautionary instructions.
Doingotherwisecouldresultinspeakersfallingandpotentiallycausing
personal injury.
• Donotjoin5ormoreHX-7SeriesSpeakerSystemstogetherina
single cluster.
• ThreeorfourHX-7SeriesSpeakerSystemsmaybejoinedtogether
only when the specified conditions for mounting brackets and
mountingmethodsaremet.
WARNING
Beforejoiningspeakersystems,layoutaprotectivesheet,corrugatedcardboardorothersoftmaterialonaat
surface,andperformallworkonthe2speakerswiththeirfrontbafesfacingdownward.Itisrecommendedthat
atleasttwopersonsbeinvolvedinjoiningspeakersystems.
Twospeakersystemscanbejoinedtogetherbyconnectingspeakermodules(AandBinthegurebelow)
usingthespeciedbrackethardware.
Note: Position speaker modules A and Bfacing in the same direction. In the gure, their side angle plate
protectioncoversarevisibleontheleftsideofeachspeakersystem.
