OFF

CHANNEL C1

CHANNEL C2

PROGRAM

u u

SWITCHINGS

NEW

SWITCHINGS

CHECK

MODIFY

NEW DATE

CHECK-MOD-

IFY-DELETE

FREE 800

HOUR

MINUTE

EVERY DAY MONDAY

SAVECOPY

ADD TUESDAY

SAVE

STANDARD

EXTRA 1 P1

EXTRA 2 P2

DELETE ALL

SWITCH

PULSE

...

MEM FREE

FIX DATE

BEFORE/

AFTER EASTER

...

P 1 DELETE

ALL

 Press MENU.

 Select PROGRAM, conrm with OK.

 Select CHANNEL (C1 to C4), conrm with OK.

 Select EXTRA 1 P1, conrm with OK.

 Select SWICHINGS NEW, conrm with OK. The display shows

MEM FREE XXX.

 Conrm with OK.

 Select SWITCH, conrm with OK.

 Select ON (for turn-on time) or OFF (for turn-off time),

conrm with OK.

 Set desired turn-on time (Mon–Fri, 7:30), conrm with OK.

The display shows EVERY DAY.

 Select MONDAY with u and conrm with OK.

 Select COPY, conrm with OK.

 ADD TUESDAY is displayed, conrm by pressing OK and also

conrm the days Wed, Thu, Fri by pressing OK.

 Continue with u until SAVE is displayed.

 Conrm with OK.

Then enter the date range via NEW DATE.

MANUAL: Setting the holiday function

MANUAL

CHANNEL C1

PERM ON

PERM OFF

OVERRIDE

TIMER

HOLIDAY

RANDOM

BEGIN

HOLIDAY

END HOLIDAY

...

 Press MENU.

 Select MANUAL, conrm with OK.

 Select CHANNEL, conrm with OK.

 Select HOLIDAY, conrm with OK.

 Select ON, conrm with OK.

 Select START HOLIDAY, conrm with OK.

 Enter YEAR, MONTH, DAY, HOUR, conrm with OK.

 Select END HOLIDAY, conrm with OK.

 Enter YEAR, MONTH, DAY, HOUR, conrm with OK.

Setting the random function

Random 1: Interruptions → several random turn-ons and

turn-offs during a programmed switch-on phase.

Random 2: → random shifting of the turn-on and turn-off

time

MANUAL

CHANNEL C1

PERM ON

HOLIDAY

RANDOM RANDOM 1

INTERRUPTIONS

RANDOM 2

SHIFTING

...

OPTIONS: ASTRO

In the standard setting, a time switch with an astro program

switches on at sunset and off at sunrise. Therefore, in most

applications, only one night switch-off (e.g. from 22:00 to

06:00) has to be programmed – and, if needed, to be copied

to all weekdays.

Astro programs can be used for precise switching of con-

nected consumers based on sunrise and sunset. They have an

additional astro pulse, which can be used for roller blinds and

blinds control.

Furthermore, the time switches offer a twilight range in three

increments:
