MIX 2 series RMG 8 T / RME 8 T actuators
Continuation:
Designation
Values
Description
Time for cyclical
transmission (time to
service and service
2 minutes, 3 minutes,
5 minutes, 10 minutes,
15 minutes, 20 minutes,
30 minutes, 45 minutes
60 minutes
At what interval?
5.3.5.13 The "Link" parameter page
This page appears when Activate link is selected on the Configuration options parameter page.
An additional object appears, which forms a logical link in combination with the channel's
switching/threshold object.
The channel only switches if the link requirement has been met.
Table 23
Designation
Values
Description
Activate link
Selection of logical link with the
channel object
AND link
The Logic input in AND gate object
appears (e.g. object 1).
OR link (override)
The Logic input in OR gate object
appears (e.g. object 1).
XOR link
The Logic input in XOR gate object
appears (e.g. object 1).
Disable object affects
logic object
No
The disable object only affects the
channel object (e.g. object 0).
If required, the logic object can activate
the channel function despite lock (with
OR and XOR link).
yes
The disable object affects the channel
object and the logic object.
The channel function is completely
blocked if the lock is active.
Version: May-14 (Subject to change) Page 52 of 87
