MIX 2 series RMG 8 T / RME 8 T actuators
5.3.5 Parameter description for the switch actuator
5.3.5.1 The "RMG 8 T basic module" parameter page
Designation
Values
Description
Sending collective
feedback
no
No collective feedback, object is
unavailable (obj. 79, 159, 239).
report as inactive
Object value cannot be requested.
only at change
Sends whenever a channel status
changes.
cyclically and at change
Sends cyclically and with status changes
See appendix: collective feedback
Relay switch delay
This parameter sets the minimum delay
between switching on two relays if
several are activated at the same time.
The shortest delay is achieved by using
the central switch object (object 242).
When switching on via individual
telegrams (1 telegram per channel) , the
bus running times and the sequential
processing of commands cause an
additional delay.
This can help avoid high current peaks
when devices are switched on
simultaneously (e.g. with a number of
lighting strips).
None
There is no added delay.
60 ms
100 ms
200 ms
When a relay switches on, the next one
can only switch on after the set delay is
completed.
The switch-on delay between the first
and last relay is calculated according to
the following formula:
(Number of channels – 1) x delay
RMG 8 T and 60 ms:
= (8 channels – 1) * 60 ms = 420 ms
The last channel switches 420 ms
after the first.
The same applies to the first or second
extension module.
Version: May-14 (Subject to change) Page 37 of 87
