MIX 2 series RMG 8 T / RME 8 T actuators
5.2.5 Description of objects for the blinds actuator (channel C1)
For the blinds function, 2 channels (e.g. C1+C5) are combined.
Therefore, the object numbers are not in consecutive order.
• Object 0 "UP/DOWN"
Raise the roller blinds/blinds with “0” and lower with “1”.
• Object 1 "Step/Stop"
If the drive moves, it will be stopped when a Step/Stop telegram is received.
If the drive is stationary at this moment, then a short slat turning (step) is performed on blinds.
With the other drive types, the current position is adjusted up or down depending on the
specified step direction.
The direction of the step is determined from whether a "0" or "1" is sent to the object.
No step is performed if the configured number of steps for a complete turn has already been
reached.
• Object 2 "% Height"
This raises/lowers the roller blinds/blinds to a certain height.
The set point value is expressed in %.
0% ... 3% = upper end position
100% = lower end position
This function can be disabled by the comfort automatic object (see below).
• Object 3 "% Slat"
Specification of a particular slat turning in %
This function can be disabled by the comfort automatic object (see below)
• Object 4 "Lock Comfort/Automatic"
A "1" on this object locks the functions Drive 1 Height and Drive 1 Slat.
This function is used to prevent the blind from being adjusted due to external influences, and
to thus maintain a preferred slat position of the blinds.
The Up/Down function (obj. 0) is maintained.
Version: May-14 (Subject to change) Page 25 of 87
