MIX 2 series RMG 8 T / RME 8 T actuators
5.2.4 Description of objects for the switch actuator (channel C1)
• Object 0 "Switch object, threshold as percent, threshold 0..255, threshold EIS 5 (DPT
9.xxx), threshold 0..65535 "
This object activates the set channel function (see parameter: Channel function).
The set channel function can either be activated via 1-bit telegram or by exceeding a threshold
(8- or 16-bit telegram).
Table 9:
Parameters
Activation of channel
function via
Activation of function via
Type of threshold object
Switch object
1-bit telegram
Exceeding the threshold
Object type: per cent (DPT
5.001)
Exceeding per cent value
Object type: counter value
0..255 (DPT 5.010)
Any value in given numerical
range
Object type: counter value
0..65535 (DPT 7.001)
Object type: EIS5 e.g. CO2,
brightness (DPT 9.xxx)
2 byte floating-point number
• Object 1 "Logic input in AND gate, in OR gate, in XOR gate"
Only available if Link is activated (configuration options parameter page).
Forms a logical link together with object 0 to activate the channel function.
• Object 2 "Lock"
Locks the channel function.
Responses to setting and cancelling the lock can be configured if the block function has been
activated (configuration options parameter page).
Version: May-14 (Subject to change) Page 22 of 87
