5 Connections and controls

1 [STANDBY | CONDITION] | Slide switch for activating (ENABLE) or deactivating (DIS‐

ABLE) power-saving mode. If the speaker is in power save mode and receives no

signal for 60 minutes, it switches to standby mode. As soon as it receives a signal, it

automatically switches back to normal mode.

The CONDITION LED lights up continuously in normal operation and goes out

when the speaker switches to standby mode if power-saving mode is enabled.

2 [BASS BOOST | FLAT | 120Hz HPF] | Preset switch:

[BASS BOOST] | Increasing the low frequencies.

[FLAT] | Even frequency response.

[120Hz HPF] | Attenuation of frequencies below 120 Hz (high pass lter).

3 [TREBLE] | Control for increasing or decreasing the high frequencies by up to 15 db

each.

4 [BASS] | Control for increasing or decreasing the low frequencies by up to 15 db.

5 [MIX OUT] | Line output for the mixed input signal from both channels.

6 [POWER ON/OFF] | Use this mains switch to turn the device on or o.

7 [INPUT] | Power Twist connection for the power supply of the device.

Achat 110 MA MKII

OUTPUT

100-240V~50/60Hz

max. 12A

Connections and controls

Achat 110 MA MKII , Achat 112 MA MKII, Achat 115 MA MKII

Active Speaker
