No. Description Qty. Item No.

1 Short anchor pin 46

7344-W10-C2B1

2 Anchor pin 25

7061-W10-C1K1

3 Joint pin 21

1156-W10-A1B

4 Shaft plug 12

7026-W10-H1K

5 Shaft pin 8

7026-W10-J3K1

6 Two-to-one converter 12

7061-W10-G1S2

7 90-degree converter X, black 2

7061-W10-J1D

8 90-degree converter Y, black 2

7061-W10-J2D

9 Curved rod, gray 2

7026-W10-V1S2

10 3-hole rod 5

7026-W10-Q2S1

11 3-hole cross rod, black 5

7026-W10-X1D

12 3-hole dual rod, gray 12

7061-W10-R1S2

13 3-hole wide rounded rod, black 6

7404-W10-C1D

14 5-hole rod B, black 6

7413-W10-K2D

15 5-hole rod C, gray 1

7413-W10-K3S1

16 5-hole dual rod B, gray 3

7026-W10-S2S1

17 5-hole dual rod C, black 2

7026-W10-S3D

18 7-hole wide rounded rod, black 5

7404-W10-C2D

19 7-hole flat rounded rod, black 5

7404-W10-C3D

20 9-hole rod 4

7407-W10-C1S

21 11-hole rod 7

7413-W10-P1D

22 15-hole dual rod 3

7413-W10-H1D

23 5x5 square frame 6

7026-W10-T2D

24 5x10 frame 2

7413-W10-I1D

25 3x13 dual frame 2

7406-W10-A1D

26 5x13 dual frame 3

7061-W10-U1D

27 5x15 frame 4

7413-W10-J1D

28 Motor shaft 6

7026-W10-L1S1

29 35-mm axle 4

7413-W10-O1D

30 65-mm axle 2

7416-W10-C1D

31 70-mm axle 11

7061-W10-Q1D

32 100-mm axle 1

7413-W10-L2D

33 Small gear, magenta 11

7026-W10-D2K

No. Description Qty. Item No.

34 Medium gear, blue 9

7346-W10-C1B1

35 Large gear, black 2

7026-W10-W5D

36 Extra large gear, yellow 3

7328-W10-G2Y

37 Worm gear 4

7344-W10-A1S1

38 Rod connector 3

7026-W10-L2D

39 Tire 2

7407-W10-A1D

40 Wheel 2

7407-W10-B1K

41 Body plate left, transparent 1

7392-W10-L1B

42 Body plate right, transparent 1

7392-W10-L2B

43 Body plate left, blue 1

7392-W10-L1B1

44 Body plate right, blue 1

7392-W10-L2B1

45 Side plate 2

7392-W10-M1B1

46 Large body plate 2

7398-W10-C1B

47 Small body plate, B 2

7398-W10-C2B

48 Left leg 1

7397-W10-C1D

49 Right leg 1

7397-W10-C2D

50 Horn 2

7128-W10-G1Y

51 Washer 2

R12#3620

52 Axle lock 1

3620-W10-A1D

53 Large foam ball 3

K30#7366-2

54 Rubber band 1

R10-02

55 Anchor pin lever 1

7061-W10-B1Y

56 Ball roller 1

1247-W85-C1S

57 Extension cord 1

1246-W85-D

58 Ultrasonic sensor 1

7416-W85-B

59 Motor (40x DDM) 2

7400-W85-A1

60 Motor (32x DDM) 2

7392-W85-B3

61 Light sensor 1

1246-W85-B

62 Touch sensor 2

1246-W85-C

63 CB1 Core controller 1

1246-W85-A1-US

64 Sticker sheet 1

R20#1246A-2

65 USB 2.0 cable 1

E30#1247A

620377- 02-170720

What’s inside your experiment kit:

Checklist: Find – Inspect – Check oﬀ

44 45 46 47

48 49 50 51 52 53 54 55

29 30 31 32 33 34 35

36 39 4037 38

› › › KIT CONTENTS

GOOD TO KNOW!

If you are missing any

parts, please contact Thames & Kosmos

customer service.

US: techsupport@thamesandkosmos.com

UK: techsupport@thamesandkosmos.co.uk

1 2 3 7 854 6 9 10 11 12

17 1816 19 2120

22 23 24

25 26 27 28

56 57 58 59

60 61 62 63 64 65

You will also need:

6 AA batteries (1.5-volt, type AA/LR6) or 6 AA

rechargeable batteries (1.2-volt, type AA, HR6/

KR6) and a tablet running iOS or Android (see

page 8 for hardware requirements)
