› › › KIT CONTENTS

What’s inside your experiment kit:

Checklist: Find – Inspect – Check oﬀ

No. Description Qty. Item No.

1 Anchor pin, black 20

7061-W10-C1D

2 Short anchor pin, gray 60

7344-W10-C2S

3 Shaft plug 1

7026-W10-H1D

4 Two-to-one converter 4

7061-W10-G1D

5 90-degree converter X 1

7061-W10-X1D

6 1-hole connector 10

7430-W10-B1D

7 3-hole cross rod 1

7026-W10-X1D

8 3-hole dual rod 2

7413-W10-Y1D

9 5-hole rod 4

7413-W10-K2D

10 5-hole cross rod 2

7413-W10-R1D

11 5-hole dual rod B 2

7413-W10-W1D

12 3-hole wide rounded rod 4

7404-W10-C1D

13 7-hole wide rounded rod 4

7404-W10-C2D

14 7-hole flat rounded rod 4

7404-W10-C3D

15 9-hole rod 2

7407-W10-C1D

16 9-hole cross rod 3

7407-W10-C2D

17 11-hole rod 3

7413-W10-P1D

18 Square frame 2

7413-W10-Q1D

19 Short frame 2

7413-W10-I1D

20 Long frame 2

7413-W10-J1D

21 3-hole bolt rod, black 2

7406-W10-B1D

22 5-hole L rod 2

7406-W10-B2D

23 Trapezoidal plate, black 2

7408-W10-A1D

No. Description Qty. Item No.

24 Trapezoidal plate, gray 2

7408-W10-A1S

25 Crankshaft gear A 1

7411-W10-C1D

26 Crankshaft gear B 1

7411-W10-C2D

27 Motor axle 2

7026-W10-L1S1

28 35-mm axle 4

7413-W10-O1D

29 60-mm axle 2

7413-W10-M1D

30 70-mm axle 2

7061-W10-Q1D

31 Small gear, gray 2

7026-W10-D2S

32 Medium gear, gray 3

7346-W10-C1S

33 Worm gear 2

7344-W10-A1D

34 Washer 6

R12#3620

35 Anchor pin lever 1

7061-W10-B1Y

36 Bluetooth battery box 1

7416-W85-G-TK-2

37 Ultrasonic sensor, gray 1

7416-W85-B-2

38 Planetary gearbox 2

7412-W85-A

39 Belt A 4

7446-W10-C1D

40 Belt B 4

7446-W10-C2D

41 Small wheel frame 2

7446-W10-B1B

42 Large wheel frame 4

7444-W10-A1B

43 Large body piece A 4

7446-W10-A1D

44 Small body piece left 4

7446-W10-A2D

45 Small body piece right 4

7446-W10-A3D

6 2 0382 - 0 2- 031221

You will also need:

•3 AA batteries (1.5-volt, type AA/LR6) or 3 AA

rechargeable batteries (1.2-volt, type AA, HR6/

KR6) and a tablet or smartphone running iOS or

Android (see page 7 for hardware requirements)

5 6 7

9 10

11 12 13

15 16 17 18 19 20

23 24 25 26 27 28

29 30

31 32 33 34 35 36 37 38 39

40 41 42 43 44 45

GOOD TO KNOW!

If you are missing any

parts, please contact Thames & Kosmos

customer service.

US: techsupport@thamesandkosmos.com

UK: techsupport@thamesandkosmos.co.uk
