WRITING PROGRAMS

DELETE ALL

To clear an entire program and set it back to the

default blank program mode, press the trash can

buon (O) in the menu bar. This also resets the

range markers to the default seings.

LOOP CHECKBOX

When the loop checkbox (P) is checked, the program

segment will run in a continuous loop, over and over

again, when the program segment is active.

When the loop checkbox is unchecked, the program

segment will run just once when the program

segment is triggered.

SWITCHING BETWEEN PROGRAMS

If you want to move to a diﬀerent program, click the

storage box buon (Q) and select which program

you want to open.

SAVING PROGRAMS

When you want to save a program you have wrien,

press the disk buon (R). The program script will

immediately be saved inside the program you are

currently in. A conﬁrmation screen will appear.

REVERT TO SAVED

To revert to the last saved version of the program

and erase all unsaved changes, press the revert to

saved buon (S).

EXITING PROGRAMMING MODE

When you want to leave the programming screen,

press the door buon (T). A window will pop up

asking if you are sure you want to leave the

programming screen. Press the green check mark

buon to go back to the main remote screen.
