Sandpaper
Use sandpaper to thoroughly remove
the burrs from all gear pieces.
STEPS
13 – 16
7
Gravity Bugs
13
16
14
Part 14 is used as a tool for
aligning the gears.
Part 11 is used as a tool for
aligning the gears.
Symbol facing up
Symbol facing up
Note the orientation. Line up the
trapezoidal notch on part 1 with the
matching notch on part 14.
Note the orientation. Line up the
trapezoidal notch on part 5 with the
matching notch on part 11.
5
11
1
14
D
15
!
It is helpful to assemble the
gearbox on a tabletop.
P4
P4
P3
P5
10
10
Many gears look alike. Part 10
has a circular column on one
side and a rectangular column
on the other side.
!
