Carefully remove all of the excess

material (burrs) before assembling.

Follow steps 1 – 4 to assemble the battery

compartment in the order shown!

Motor

Switch

Positive

terminal

Negative

terminal

Sandpaper

First cut off the burrs using

diagonal cutters or scissors.

Then, use sandpaper to

remove any remaining burrs.

Positive

terminal

STEPS

1 – 4

Use one of the prongs of

part 14 as a tool to push the

positive terminal all the way

into the slot.

Use one of the prongs of

part 14 as a tool to push

the negative terminal all

the way into the slot.

Insert the positive terminal, which is attached to

the red wire, into the slot next to the symbol.

Make sure the round

protrusion on the

terminal is facing the

inside of the battery

compartment.

Negative

terminal

Insert the negative

terminal, which is attached

to the black wire, into the

slot next to the symbol.
