STEPS
32–34
12
32
33
34
Attach two legs to each side of the body
as shown. Each leg requires two locking
bolts, so you will need a total of eight
locking bolts.
Attach the four suction-cup feet to the legs. Pay attention to the direction of
the arrow pattern on the tops of the feet when sliding the feet onto the legs.
Add two drops of olive oil (or other cooking oil) to the rim of each gray gear
that attaches to the legs
Lock each bolt in place by using one prong
of part 14 as a screwdriver. To lock, turn the
bolt counterclockwise until it click. (Turn the
bolt clockwise to unlock.)
7
7
1618
x2 x2
Lock
Unlock
B
T
I
p
If you switch it on now,
and the legs don’t move,
take the model apart and
build it again.
Inspect each of the gray
Gears, and carefully remove
any burrs with sandpaper.
Oil the rim of
each wheel.
14
