Televés T.0X TWIN 5806 handleiding
Handleiding
Je bekijkt pagina 18 van 32
Twin Modulator
18
b. Temperature Menu
The following menu provides an indication of
the unit’s current temperature as well as the
maximum recorded. The maximum can be reset by
pressing the key .
The recommended operating margins are as
follows:
• Optimum operation : 0-6
• High temperature: 7-8
• Excessive temperature: 9-10
If the maximum recorded is outside the optimal
range the installation should be adjusted to try to
lower the temperature.
c. Version Menu
Pressing accesses the following menu. Muestra
por pantalla información acerca de la versión de
FW que tiene cargada la unidad (microprocesador,
boot).
d. Language Menu
Pressing the key accesses the next extending
menu. This menu allows selection, between
Spanish, English and German of the language in
which to display the LCD screen text.
The language is changed directly using the keys
and .
LANGUAGE
English
IDIOMA
Espa¤ol
SPRACHE
Deutsch
5.3. Parameters Saving
Once a parameter is modied to the desired value
in any menu (normal or extended), to save the
settings press for three seconds. The display will
show the following indication:
Please, do not unplug the programmer until this
indication disappears. Then the Output Menu will
be displayed with the video frequency (or channel
number) of the output channel.
If the conguration paremeters are modied but
not saved, the previous conguration is retrieved
after 30 sec. in other words, the changes are
discarded.
