Technical Specifications
Frequency
Range 50 - 880 MHz and 950 - 2400 MHz
Resolution 125 kHz
Tuning Frequency or channel
Input
Impedance 75Ω F-type connector
Spectrum Analyzer
Span 5, 10, 20, 50, 100, 200, 500 and Full span
Scale 5 and 10 dB/div
Hold mode
Auto and manual
reference level
Return Channel
Optical Fiber
(Sel.OF: 593601/02/03/04/61 - Non-SelFO: 593621/22/24)
No Selective -40dBm to +7dBm
Selective -40dBm to +7dBm
RF Overlay -10dBm to +5dBm
Optical Attenuation
Digital Measurements DVB-T (ref. 593601, 593602, 593604, 593621,
593622, 593624 and opt. 593231)
MPEG image
Modulations CFDM (QPSK, 16QAM, 64QAM)
Power 45-110dBuV (25-120dBuV opt.593235)
CBER 9.9E-2 - 1.0E-6
VBER 1.0E-3 - 1.0E-8
MER Up to 35dB
C/N Up to 40dB
Echoes
Constellation
Digital Measurements DVB-T2 (ref. 593602, 593604, 593622 and
opt. 593232)
MPEG image
Modulations COFDM (QPSK, 16QAM, 64QAM and 256QAM)
Power 45-110dBuV (25-120dBuV opt.593235)
LDPCBER 9.9E-2 - 1.0E-6 (Pre LDPCBER)
BCHBER 1.0E-3 - 1.0E-8 (Pre BCHBER or Post LDPCBER)
Link Margin Up to 30dB
MER Up to 35dB
C/N Up to 40dB
Echoes
Constellation
Digital Measurements DVB-C (ref. 593603, 593604, 593624 and opt.
593233)
MPEG image
Modulations 16QAM, 32QAM, 64QAM, 128QAM and 256QAM
Power 45-110dBuV (25-120dBuV opt.593235)
CBER 1.2E-2 - 1.0E-8
MER Up to 38dB
C/N Up to 40dB
Constellation
Digital Measurements DVB-S
MPEG image
Power 45-110dBuV (25-120dBuV opt.593235)
CBER 9.9E-2 - 1.0E-6
VBER 1.0E-4 - 1.0E-8
MER Up to 20dB
C/N Up to 20dB
Constellation
Digital Measurements DVB-S2
MPEG image
Modulations
QPSK, 8PSK
Power 45-110dBuV (25-120dBuV opt.593235)
Link Margin
Up to 10dB
MER
Up to 20dB
LDPCBER
9.9E-2 - 1.0E-6 (Pre LDPCBER)
BCHBER
9.9E-2 - 1.0E-8 (Pre BCHBER or Post
Constellation
Digital Measurements ISDB-T/Tb (ref.593661)
MPEG image
Modulations DQPSK, QPSK, 16QAM and 64QAM)
Power 45-110dBuV (25-120dBuV opt.593235)
Pre-BER (by layer) 9.9 E-2 - 1.0E-6
Post-BER (by layer) 1.0 E-3 - 1.0E-8
MER Up to 35dB
C/N Up to 40dB
Echoes
Constellation
Analog Measurements
Level 25 - 125dBuV
V/A
C/N Up to 45dB
Features
Terrestrial and
Satellite channel
plans
Channel plans from dierent world wide regions
User channel plans
Units dBuV, dBmV, dBm
Preamp powering 13, 18, 24Vdc (max. current 475, 370, 140mA)
LNB powering 13, 18Vdc (max. current 475, 370mA)
LNB tone 22KHz
SCR (EN 50494) | dCSS
(EN 50607)
| Opt.593234
DiSEqC
Wi-Fi Analyser Opt. 593250
Video Camera Opt. 593236
IPTV Analyser Opt. 593251
HEVC visualization Opt. 593252 (up to 1080p)
Specications are subject to change without notice.
