H30 CRYSTAL
20
11. Video Camera (opt.
593236)
This feature allows the H30Crystal meters to have
an analog video and audio input using an external
USB 2.0 adapter, with capability to digitize the
analog input signals.
It is specically aimed for installation and
maintenance of analog video surveillance systems.
The supported interface is composite RCA (S-VHS).
The input video formats that can be displayed are
the following:
• NTSC: 720x480 @ 30fps
• PAL: 720x576 @ 25fps
To run the feature you just have to connect the
input signal to the adaptor provided with the
H30Crystal, making sure that the adaptor is
connected to the USB input of the meter. If there
is something wrong, the next screen will be shown:
11.1. Main window
Below is a capture of a Camera window:
12. Wi-Fi Scan (opt. 593250)
Analyzes the Wi-Fi band and automatically detects
all the Wi-Fi networks, as well as their names and
the power of the access point signal.
There are two dierent screens to display the
information: List and Map.
12.1. List view
You can go through the list using and select
one of the Wi-Fi networks to display it separately.
If a Wi-Fi network has multiple access points, you
will see several networks with the same name. If
you select one of them, you will separately all the
access points of that network. The rst one in the
list is the one you are connected to, which is the
one that has more signal power at that point.
Power of each Wi-Fi
access point signal.
The list is sorted by
power
Wi-Fi network channel
Wi-Fi network name
The red lock indicates
that the network is
locked
Wi-Fi network MAC
Wi-Fi protect access type
