English - 10 -

on the top of the screen as an info banner. This option

is intended only for store use. It is recommended to

select Home Mode for home use. This option will be

available in System>Settings>More menu and can be

turned o󰀨/on later.

Press OK button on the remote control to continue.After

the initial settings are completed TV will start to search

for available broadcasts of the selected broadcast types.

After all the available stations are stored, scan results

will be displayed. Press OK to continue. The Edit

Channel List menu will be displayed next. You can edit

the channel list according to your preferences or press

the Menu button to quit and watch TV.

While the search continues a message may appear,

asking whether you want to sort channels according

to the LCN(*). Select Yes and press OK to conrm.

(*) LCN is the Logical Channel Number system that organizes

available broadcasts in accordance with a recognizable channel

number sequence (if available).

Note: Do not turn o the TV while initializing rst time installation.

Note that, some options may not be available depending on

the country selection.

Media Playback via USB Input

You can connect 2.5” and 3.5” inch (hdd with external power

supply) external hard disk drives or USB memory stick to your

TV by using the USB inputs of the TV.

IMPORTANT! Back up the les on your storage devices

before connecting them to the TV. Manufacturer will not

be responsible for any le damage or data loss. Certain

types of USB devices (e.g. MP3 Players) or USB hard

disk drives/memory sticks may not be compatible

with this TV. The TV supports FAT32 and NTFS disk

formatting.

Wait a little while before each plugging and unplugging

as the player may still be reading les . Failure to do

so may cause physical damage to the USB player and

the USB device itself. Do not pull out your drive while

playing a le.

You can use USB hubs with your TV’s USB inputs.

External power supplied USB hubs are recommended

in such a case.

It is recommended to use the TV’s USB input(s) directly,

if you are going to connect a USB hard disk.

Note: When viewing image les the Media Browser menu

can only display 1000 image les stored on the connected

USB device.

Media Browser Menu

You can play photo, music, and movie les stored on a

USB disk by connecting it to your TV. Connect a USB

disk to one of the USB inputs located on the side of

the TV. Pressing the Menu button while in the Media

Browser mode will access the Picture, Sound and

Settings menu options. Pressing the Menu button

again will exit from this screen. You can set your Media

Browser preferences by using the Settings Menu.

Loop/Shue Mode Operation

Start playback with the Play

button and activate

All les in the list will be

continuously played in original

order

Start playback with the OK

button and activate

The same le will be played

continuously (repeat)

Start playback with the Play

button and activate

All les in the list will be

played once in random order

Start playback with the Play

button and activate ,

All les in the list will be

continuously played in the

same random order.

CEC

This function allows to control the CEC-enabled devices,

that are connected through HDMI ports by using the

remote control of the TV.

The CEC option in the System>Settings>More menu

should be set as Enabled at rst. Press the Source

button and select the HDMI input of the connected CEC

device from the Sources List menu. When new CEC

source device is connected, it will be listed in source menu

with its own name instead of the connected HDMI ports

name(such as DVD Player, Recorder 1 etc.).

The TV remote is automatically able to perform the

main functions after the connected HDMI source has

been selected.

To terminate this operation and control the TV via the

remote again, press and hold the “0-Zero” button on the

remote control for 3 seconds. This feature can also be

enabled or disabled under the System>Settings>More

menu.

The TV supports also ARC(Audio Return Channel)

feature. This feature is an audio link meant to replace

other cables between the TV and the audio system (A/V

receiver or speaker system).

When ARC is active, TV does not mute its other audio

outputs automatically. So you need to decrease TV

volume to zero manually, if you want to hear audio from

connected audio device only (same as other optical or

co-axial digital audio outputs). If you want to change

connected device’s volume level, you should select that

device from the source list. In that case volume control

keys are directed to connected audio device.

Note: ARC is supported only via the HDMI2 input.

System Audio Control

Allows an Audio Amplier/Receiver to be used with the

TV. The volume can be controlled using the remote

control of the TV. To activate this feature set the

Speakers option in the System>Settings>More menu

as Amplier. The TV speakers will be muted and the

sound of the watched source will be provided from the

connected sound system.

Note: The audio device should support System Audio Control

feature and CEC option should be set as Enabled.
