English - 9 -

Switching On/O󰀨

To Switch the TV On

Connect the power cord to a power source such as a

wall socket (220-240V AC, 50 Hz).

To switch on the TV from standby mode either:

• Press the Standby button, Programme +/- or a

numeric button on the remote control.

• Press the control button on the TV.

To Switch the TV O󰀨

• Press the Standby button on the remote control.

• Press the control button on the TV, the function

options menu will be displayed. The focus will be

on the Standby option. Press and hold the button

for about 2 seconds to activate this option. The icon

colour of the option will change. Then press the

button once again, the TV will switch into standby

mode.

To power down the TV completely, unplug the

power cord from the mains socket.

Note: When the TV is switched into standby mode, the standby

LED can blink to indicate that features such as Standby Mode

Search or Over Air Download is active. The LED can also blink

when you switch on the TV from standby mode.

First Time Installation

When turned on for the first time, the language

selection screen is displayed. Select the desired

language and press OK.

On the next screen, set your preferences using the

directional buttons.

Note: Depending on the Country selection you may be asked

to set and conrm a PIN at this point. The selected PIN cannot

be 0000. You have to enter it if you are asked to enter a PIN

for any menu operation later.

About Selecting Broadcast Type

Digital Aerial: If Digital Aerial broadcast search option

is turned on, the TV will search for digital terrestrial

broadcasts after other initial settings are completed.

Digital Cable: If Digital Cable broadcast search

option is turned on, the TV will search for digital cable

broadcasts after other initial settings are completed.

According to your other preferences a conrmation

message may be displayed before starting to search.

Select YES and press OK to proceed. To cancel

operation, select NO and press OK. You can select

Network or set values such as Frequency, Network

ID and Search Step. When nished, press OK button.

Note: Searching duration will change depending on the selected

Search Step.

Satellite: If the research option Satellite is switch-on,

TV will search for digital satellite channels after other

initial settings are completed.

Before performing the satellite search, some settings

should be made:

If the type of installation is standard, you can select

Antenna’s Type on Direct, Single Satellite Cable or

DiSEqC Switch using the button “ ” or “ ” .

Direct: If you have a single receiver and a direct

parabola, select this type of antenna. Press OK

button to continue. Select a satellite available on the

next screen and press OK for the scan of the services.

Single Satellite Cable: If you have multiple receivers

and a single satellite cable, select this type of antenna.

Press OK button to continue. Congure the settings by

following the instructions on the next screen. Press OK

to scan the devices.

DiSEqC switch: In case you have a multiple LNB or

multiple satellite dish and a DiSEqC switch, select this

type of antenna. Press OK button to continue. It will

be possible to set four DiSEqC options (if available)

on the next screen. Press OK button to scan the rst

satellite in the list.

If the installation type is Operator - Tivusat will be made

a research for the channels on the Hot Bird 13 East

satellite according to Tivusat order.

It will be possible select Antenna’s Type on Direct ,

Single Satellite Cable or DiSEqC Switch by using the

“ ” or “ ” buttons.

Direct: If you have a single receiver and a direct

parabola, select this type of antenna. Press OK button

to continue. On the next screen will appear the Hot

Bird (13.0E) satellite imposted, press OK for the scan

of the services.

Single Satellite Cable: If you have multiple receivers

and a single satellite cable, select this type of antenna.

Press OK button to continue. Congure the settings by

following the instructions on the next screen. Press OK

to scan the devices.

DiSEqC switch: In case you have a multiple LNB or

multiple satellite dish and a DiSEqC switch, select this

type of antenna. Press OK button to continue. It will

be possible to set four DiSEqC options (if availables)

on the next screen. Press OK button to scan the rst

satellite in the list.

Analogue: If Analogue broadcast search option is

turned on, the TV will search for analogue broadcasts

after other initial settings are completed.

Additionally you can set a broadcast type as your

favourite one. Priority will be given to the selected

broadcast type during the search process and the

channels of it will be listed on the top of the Channel

List. When nished, press OK to continue.

You can activate Store Mode option at this point.

This option will congure your TV’s settings for store

environment and depending on the TV model being

used, the supported features of it may be displayed
