9 Product description

9.1 Front

In the lower front part of the TV, usually on the right (the position may vary depending on the model of

TV), there are the following adjacent components:

1. LED: LED status indicators: on (GREEN), standby (ROSSO) and remote-control operation (flashing

RED).

2. IR: Infrared sensor for the remote control.

9.2 Keyboard

The keyboard, normally located on the right side of the TV (the position may vary depending on the TV

model), includes the following function keys:

1. VOL+ e VOL-: audio volume regulation.

2. CH+ e CH-: previous/next channel change.

3. MENU: access the main menu.

4. SOURCE: input source selection/TV mode.

5. POWER: power on/turn off in Standby mode.

9.3 Connections

The following inputs and outputs are available behind the TV:

1. USB (x2): USB2.0 ports for connecting USB mass storage devices for multimedia playback (Media

player function).

2. Headphone: headphone output (3,5mm jack).

3. YPbPr: Video Component input (YPbPr). Optional external adapter required.

4. CI/CI+: housing for CI/CI + common interface modules.

5. COAXIAL: coaxial digital audio output.

6. HDMI1, HDMI2, HDMI3: HDMI digital audio-video inputs (v.1.4) for connecting an external AV source

(e.g. a receiver or DVD player) equipped with an HDMI interface.

7. RF IN (T2/C): antenna input (IEC type) for receiving digital terrestrial (DVB-T / T2) or cable (DVB-C)

signal.

8. RF IN (S2): SATELLITE RF Antenna input (type F).

9. SCART/RCA: analogue audio-video input for connecting an AV device with a RCA (CVBS + Stereo

Audio) interface.

10. PC Audio IN and PC VGA: audio inputs (3.5mm jack) and video (VGA) for connecting a Personal

Computer.

11. LAN: Ethernet (RJ45) port for connection to the Internet, necessary for the Smart TV function.

12. Supply: integrated power cable for connecting the television to the 230VAC, 50Hz mains supply.
