4. T

urn the Multipurpose knob to select the Year field.

5. Click the Multipurpose knob to enable setting the year value. A white box is drawn around the number field, indicating that you can

use the Multipurpose knob to change that value.

6. T

urn the Multipurpose knob to change the year value in the field.

When the value is correct, click the Multipurpose knob. This enters the number and returns the knob to menu select mode.

7. Repeat steps 2 - 5. to select and change the remaining date and time settings (Month, Day, Hour, Minute).

Getting acquainted with the oscilloscope

TBS1000C Series Oscilloscopes User Manual 39
