INSTALLATION
4) FIXING THE HOT PLATE
The hot plate has a special seal which prevents
liquid from infiltrating into the cabinet. Strictly
comply with the following instructions in order to
correctly apply this seal:
- take off all the movable parts of the hob.
- Cut the seal in 4 parts of the necessary lenght to
positionning it on the 4 edges of the crystal.
- Overturn the hot plate and correctly position seal
“E” (fig. 15/A) under the edge of the hot plate
itself, so that the outer side of the seal perfectly
matches the outer perimetral edge of the crystal.
The ends of the strips must fit together without
overlapping.
- Evenly and securely fix the seal to the crystal,
pressing it in place with the fingers.
FIXING HOOKS
Phase 1
- Place the hooks chrome in their respective
positions, use the hole no. 1 as reference for
position lateral (fig. 9 - 10/C - 11 - 13),
depending on the model;
- secure hooks “G” by means of screws “F” (fig.
9/A for lateral).
Phase 2
- Place the hooks black use the hole no. 2 for
positions rear (fig. 10 - 10/D - 12 - 14),
depending on the model.
- Secure hooks “G” by means of screws “F” (fig.
10/A for rear).
Phase 3
- Insert the cooking hob in the hole of the kitchen
cabinet (direction 1), exerting a slight downward
pressure (2) by exercising a certain level of force
in order to get over the resistance of the hooks
(fig. 9/B for lateral and fig. 10/B for rear).
- In order to avoid accidental touch with the
overheating bottom of the hob, during the
working, is necessary to put a wooden insert,
fixed by screws, at a minimum distance of 70
mm from the top (see fig. 7).
Model: GBC 32000
- Position the hob in the hole in the unit and fasten
it in place using the appropriate screws “F” of the
fastening hooks “G” (see fig. 15).
Caution: Do not allow the glass (A) lay directly on the work top. it is the metal bottom “carter”
(B) that has to be in touch with the work top (see fig. 15/B).
CAUTION:
do not place the glass directly on the unit.
The bottom of the hob must rest on
the unit.
32
