With hobs CG Lux-75 and CG Lux-86 you
can use pans with a concave base (e.g.
woks) on the grid that is designed for this
use.
Only pans with a minimum diameter of 140
mm should be used on each burner. If you
wish to use a pan with a diameter of 120
mm or smaller, it should be placed on the
auxiliary burner. On hobs CG Lux-75 and
CG Lux-86, the grid accessory has to be
used (element A in fig. 8).
The device shall not be operated
for more than 15 seconds. If after 15
seconds the burner has not lit, stop the
device and open the compartment door
and/or wait at least 1 minute before
attemting a futher ignition of the burner.
Anti-accidental turn system
on gas controls
On models without the safety sys-
tem (without the gas cut-off device), the
gas taps are equipped with a mechanical
system that prevents the controls from
being freely turned from the off position to
the on position (and, therefore, prevents
any accidental escape of gas from the bur-
ners) if the control has not previously
been pressed down.
If at any time while using the hob
you notice that a control can be turned
from the off position without it needing
to be pressed down beforehand (for
example: due to dirt which may have
got into the gas taps and built up there)
you should, for your own safety, get
quickly in touch with technical assis-
tance in order to resolve this fault.
Safety system
components
On hobs with the safety feature (those
models which have the letters AL), the gas
cut-off device is made up of these ele-
ments:
* The safety tap
GB
20
‘Burner in operation’ indicator
Control indicator
Off position
Maximum gas position
Minimum gas position
Burner on position
fig. 10
Safety thermocouple
Thermocouple-tap connection
Spark generation connection
Ignition spark plug
Ceramic head
Electrode
Safety tap
fig. 11
