14
Important Notes
Levelling the Feet
INSTALLATION
Overhead clearances
In no case shall the clearances between the highest part of the cooker be less than 650mm
or for an overhead exhaust fan 750 mm. All other downward facing combustible surfaces less
than 650 mm above the cooker surface shall be protected for the full width of the cooking surface
in accordance with the standards noted above. In no case shall the clearance be less than 450 mm.
Rear and side clearances
• Where the dimensions from the periphery of the nearest burner to any vertical combustible surface
is less than 200 mm the surface shall be protected in accordance with the standards to a height of
not less than 150 mm above the cooking surface for the full width or depth of the cooking surface.
• Where the dimensions from the periphery of the nearest burner to any horizontal
combustible surface is less than 200 mm, the horizontal surface shall be greater than
10 mm below the surface of the hob, or the horizontal surface requirement above.
• Do not install the range near flammable materials such as curtains.
Installing the range on a plinth
• The freestanding oven can be installed on a plinth without the adjustable legs fitted.
• Ensure the freestanding oven is secure and provide safety measures to keep it in place.
• Cabinetry dimensions can be adjusted to suit the plinth height, see product dimensions for chassis height.
The height and level of the appliance can be
adjusted by rotating the feet located underneath
the appliance at each corner. Rotate the feet to
decrease or increase the height.
