32
APPENDIX – TECHNICAL SPECIFICATIONS
Digital Input and Output
Connector:
Formats:
Sample Rates:
Processing Delay:
Frequency Response DIO:
Analog Inputs
Connectors:
Impedance, Bal / Unbal:
Max. / Min. Input Level
@ 0 dBFS:
Sensitivity Range
@ 12 dB headroom:
A to D Conversion:
A to D Delay:
Dynamic Range:
THD:
Frequency Response:
Crosstalk:
Analog Outputs
Connectors:
Impedance Bal / Unbal:
Max. Output Level:
D to A Conversion:
D to A Delay:
Dynamic Range:
THD:
Frequency Response:
Crosstalk:
EMC
Complies with:
Safety
Certified to:
Environment
Operating Temperature:
Storage Temperature:
Humidity:
Control Interface
MIDI:
Pedal:
General
Finish:
Display:
Dimensions:
Weight:
Mains Voltage:
Power Consumption:
Warranty Parts and labor:
RCA Phono (S/PDIF)
S/PDIF (24 bit), EIAJ CP-340, IEC 958
44.1 kHz. (44.1 kHz and 48 kHz @ Digital Input)
0.08 ms @ 48 kHz
DC to 23.9 kHz ± 0.01 dB @ 48 kHz
1/4" phone jack balanced, mono sense
21 kOhm / 13 kOhm
+24 dBu / 0 dBu
-12 dBu to +12 dBu
24 bit, 128 x oversampling bitstream
0.70 ms / 0.65 ms @ 44.1 kHz / 48 kHz
typ < -92 dB, 22 Hz to 22 kHz
typ < -90 dB (0.0032 %) @ 1 kHz, -1 dBFS
+0/-0.1 dB, 20 Hz to 20 kHz
typ < -100 dB, 20 Hz to 20 kHz
1/4" phone jack balanced
40 Ohm / 20 Ohm
+14 dBu
24 bit, 128 x oversampling bitstream
0.68 ms / 0.63 ms @ 44.1 kHz / 48 kHz
typ < -105 dB typ, 22 Hz to 22 kHz
typ < -97 dB (0.0014 %) @ 1 kHz, +13 dBu
+0/-0.5 dB, 20 Hz to 20 kHz
typ < -100 dB, 20 Hz to 20 kHz
EN 55103-1 and EN 55103-2
FCC part 15, Class B, CISPR 22, Class B
IEC 65, EN 60065, UL6500 and CSA E60065
CSA FILE #LR108093
32° F to 122° F (0° C to 50° C)
-22° F to 167° F (-30° C to 70° C)
Max. 90 % non-condensing
In/Out: 5 Pin DIN
1/4" phone jack
Anodized aluminum front
Plated and painted steel chassis
2 x 7 segment + LED’s
19" x 1.75" x 4.2" (483 x 44 x 105.6 mm)
3.3 lb. (1.5 kg)
100 to 240 VAC, 50 to 60 Hz (auto-select)
<15 W
1 year
Due to continuous development, these specifications
are subject to change without notice.
