58 TASCAM FR-AV2 V1.00
15. Timecode functions
Outputting timecode
Set TC GEN MODE to anything other than “OFF” and set the
following.
TIMECODE screen
e
Select TC OUT LEVEL and
press the F4[ENTER] button.
Select “LTC” or “MIC” and
press the F4[ENTER] button.
OFF (default)
Audio will be output from the line output.
LTC
Select this to input the timecode output to another device
that receives timecode. (1.8Vpp)
MIC
Select this to input the timecode output to a camera.
(50mVpp)
o Select the output setting according to the input specications
of the device receiving the timecode.
o When outputting audio from the line output, set it to “OFF”.
o When TC OUT LEVEL is set to LTC or MIC, LTC will be output
from the line output.
In this case, “TC OUT” will be shown on the HOME screen.
TIMECODE INFORMATION
This shows the timecode that is being received or sent.
TIMECODE screen
e
Select INFORMATION and
press the F4[ENTER] button.
After conrming, press the
F1[BACK] button.
TIMECODE
This shows the timecode as hours: minutes: seconds: frames.
USERBITS
This shows the user bits (date, time, scene number or other
chosen data) set with the AtomX SYNC/UltraSync BLUE or
other device.
FPS
This shows the frame rate.
DEVICE
This shows the name of the AtomX SYNC/UltraSync BLUE or
other device.
FREE RUN
Set the behavior when TC GEN MODE is set to “FREE RUN”.
TIMECODE screen
Select the item to set and
press the F4[ENTER] button.
START TIME
This sets the initial timecode value.
FRAME TYPE
This sets the FPS during free running operation.
The default value is 29.97DF.
RESTART
This restarts timecode from the “ START TIME” setting.
NOTE
If the unit power is turned o during free running operation
and then turned on again, timecode will start with the initial
value set by START TIME.
