34
ELITE
User Manual
©2025 AMETEK SurgeX | B01-00014 (REV A) Technical Support: 800-645-9721 | surgex.com
10.Specications
PARAMETER SX-AEP-159 SX-AEP-209 SX-AEP-1011i SX-AEP-1611i
AC Load Rating 12A @ 120V 16A @ 120V 10A @ 240V 16A @ 240V
No of Outlets - back 8 8 10 10
No of Outlets - front 1 1 1 1
Measurement
Accuracy
Voltage ± 2%
Current ± 5%
Power ± 7%
Energy ± 7%
Timestamp Accuracy ± 1%
Auxiliary Relay Control (2) 3 x screw terminal
Contact Closure (1) 2 x screw terminal
Temperature Sensor Input (1) 4 x screw terminal
Serial Port RS232 port
Network Port
10/100 Ethernet connection on Female RJ-45, Auto Negotiating with 10/100
network connections with Link and Activity LEDs
Micro USB
Weight 12.4 Lbs/5.6Kg 12.4 Lbs/5.6Kg 11.9 Lbs/5.4Kg 11.9 Lbs/5.4Kg
Dimensions
(Enclosure)
Height: 1.73”/44mm 1.73”/44mm 1.73”/44mm 1.73”/44mm
Width: 17.4”/442mm 17.4”/442mm 17.4”/442mm 17.4”/442mm
Depth: 11.8”/300mm 11.8”/300mm 11.8”/300mm 11.8”/300mm
Temperature Range: 100% Load 0 to 45 °C (32 - 113 °F)
Humidity Range 5% to 95% R.H. Non-condensing
Altitude 0 - 10000ft (0 - 3048meters)
Agency
Listings
Safety
CertiedtoUL62368-1 CertiedtoUL62368-1
CAN/CSA C22.2 No 62368-1:19,
3rd Ed
CE Mark
RoHS: Compliant WEEE
Prop 65
RoHS: Compliant
REACH: Compliant
Surge / EMI
FCC 47 CFR PART 15 SUBPART B
(Using ANSI C63.4-2014)
EN 55035:2017+A11:2020
EMC ICES-003 ISSUE 7
EN 55032:2015 + A1:2020
EN IEC 61000-3-2:2019 + A1:2021
EN 61000-3-3:2013 + A2:2021
Surge Protection Advanced Series Mode
IP protection class IPX0
AC Power System Type TN
Pollution Rating Pollution degree (PD) PD 2
