© 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com 12
User Manual
Firmware Version v2.10.300
5.5.1 Device Setup
The Device Setup page allows for the
specification of basic device
parameters.
Saving any change which requires a
reboot to take effect will result in the
addition of a “Reboot Required” button
at the bottom of the page.
Device Setup
Item
Description
On Power Up
Specify whether to set outlets to Initial States or run a predefined Sequence when the Axess Elite
powers up, or the Reset button is pushed, or a soft reboot is commanded.
Device Name /
Hostname
Specifies the name label to be associated with the Axess Elite. This name also serves as the
Hostname.
Power Up Delay
Time
Specifies the amount of time in seconds by which to stagger the manual turning on of multiple
outlets.
Reboot Time
Specifies the amount of time an outlet is to remain off during a Reboot operation.
Temperature Display
Specifies whether to display temperature in degrees Fahrenheit or Celsius.
User Accounts May
Clear Shutdown
Specifies whether or not a non-administrative user account is allowed to manually clear a
persistent shutdown state.
Serial Baud Rate
Specifies the baud rate to be used with the serial interface.
Serial Port Requires
Login
Specifies whether or not a serial CLI session requires login.
Auto Logout
Specifies the web and telnet security timeout in minutes.
Use History Logging
Specifies whether or not to keep an internal log file.
Allow Firmware Upgrade
Specifies whether or not the Axess Elite is in an upgradeable state.
Outlet Name
Allows for the specification of name labels for each outlet.
Initial State
Specifies the state the outlet will take following a loss of power or the clearing of a shutdown
event.
ICE
Specifies whether or not to activate Inrush Current Elimination for outlets 1 and 2.
On Shutdown Clear
Specify whether to set outlets to Initial States or run a predefined Sequence when a Shutdown
State clears.
Aux 1 Confirmation
Enables/disables "Confirmation Mode" for Aux Relay 1, wherein Aux 1 will be latched only when
all AC outlets are On.
