© 2019 AMETEK Electronic Systems Protection | Technical Support: 800-645-9721 | surgex.com 11
User Manual
Firmware Version v2.10.300
5.4 Global View
The Global View page displays
the current outlet states and
system status for the Axess
Elite and expansion units. Up
to 15 expansion units may be
set up on the Links Setup page.
Outlets and Aux Relays may
be commanded to turn On, Off,
or Reboot for up to 16 Axess
Elite units (1 master and 15
expansions).
In order to have rights to control expansion unit outlets, the user’s identical user name and password must be
programmed into each expansion Axess Elite to be managed.
5.5 Setup
Complete setup and configuration of the Axess Elite is provided via 7 Setup web pages. Each setup page
is described in the following sections.
Setup
Setup Page
Description
Device
Configure basic device parameters
Network
Configure network settings, including the network adapter, email, and time keeping
Network Reporting
Configure SNMP, SDxP, and Syslog reporting
Users
Configure user accounts
Triggers
Configure System Triggers
Create and modify User Triggers
Sequences
Create and modify custom Sequences
Links
Create and modify Expansion units and Favorite links
