NVMe I²C Header
Connector JNVI²C1 on the X14SBT- GAP motherboard is a management header for the
Supermicro AOC NVMe PCIe peripheral card. Connect the I²C cable to this connector.
For a detailed diagram of the X14SBT- GAP motherboard, see the layout under "Quick
Reference" on page 12.
Rear I/O Module Connector
There is a Rear I/O Module Connector on the X14SBT-GAP motherboard at JRIO1. Connect
this to provide a VGA port, Dedicated BMC LAN access, and two USB 3.0 ports to the
motherboard.
For a detailed diagram of the X14SBT- GAP motherboard, see the layout under "Quick
Reference" on page 12.
TPM/Port 80 Header
The JTPM1 header on the X14SBT-GAP motherboard is used to connect a Trusted Platform
Module (TPM)/Port 80, which is available from Supermicro (optional). A TPM/Port 80 connector
is a security device that supports encryption and authentication in hard drives. It allows the
motherboard to deny access if the TPM associated with the hard drive is not installed in the
system. Information on the TPM is available at the following page:
https://www.supermicro.com/manuals/other/AOM-TPM-9670V_9670H__X12_H12.pdf
For a detailed diagram of the X14SBT- GAP motherboard, see the layout under "Quick
Reference" on page 12.
Trusted Platform Module Header
Pin Definitions: 10 Total
Pin# Definition Pin# Definition
1 +3.3 V 2 SPI_CS#
3 RESET# 4 SPI_MISO
5 SPI_CLK 6 Ground
7 SPI_MOSI 8 No Connection
9 +1.8 V Standby 10 SPI_IRQ#
Jumper Settings
To modify the operation of the motherboard, jumpers can be used to choose between optional
settings. Jumpers create shorts between two pins to change the function of the connector. Pin
1 is identified with a square solder pad on the printed circuit board. See the diagram below for
53
X14SBT-GAP: Component Installation
