3. Gently lift the PHM upwards to remove it from the socket.
Figure 2-34. Remove the PHM from the Socket (2U left, 4U right)
4. To remove the processor from the heatsink, gently lift the lever from the processor
carrier.
Figure 2-35. Carrier with Heatsink (2U left, 4U right)
5. To remove the processor, move the lever to its unlocked position and gently remove the
processor.
Figure 2-36. Processor Removal
42
X14SBT-GAP: Component Installation
