+3.3 V Standby Power
Pin Definitions: Five Total
Pin# Definition
10 +3.3 Standby
11 Ground
12 I²C Data
13 I²C Clock
14 Ground
Power Fail LED Indicators
Power Failure LED Indicators are located on pins 15 and 19 of JFP1 on the X14SBH-AP
motherboard.
For a detailed diagram of the X14SBH- AP motherboard, see the layout under "Quick
Reference" on page 12.
FP Power LED
Pin Definitions (JFP1)
Pin# Definition
15 PWR Failure LED-Positive
19 PWR Failure LED-Negative
Input/Output Ports
For information about input/output ports on the X14SBH-AP motherboard, refer to the following
content.
I/O Ports
I/O Ports
# Description
1 JAIOM1
2 PSU2
3 PSU1
59
X14SBH-AP: Component Installation
