2.6 Connections, Jumpers, and LEDs
Refer to the following sections for information about connections, jumpers, and LEDs for the
X14DBT-FAP/-FLAP motherboard.
Power Supply and Power Connections
For information about the power connections of the X14DBT-FAP/-FLAP motherboard, refer to
the following content.
Power Supply
As with all computer products, a stable power source is necessary for proper and reliable
operation. It is even more important for processors that have high CPU clock rates where noisy
power transmission is present.
The X14DBT-FAP/-FLAP FlexTwin Server board accommodates one Supermicro proprietary
power supply unit (JPWR1), and three 4-pin +12 V power connectors (JPMW1–JPMW3).
Although most power supplies generally meet the specifications required by the processors,
some are inadequate. All these power connections are also required to ensure adequate power
supply to the system.
Important: To avoid damaging the power supply or the motherboard, be sure to use a power
supply that accommodates two power supply units. Be sure to also connect the power
supplies to eight 8-pin +12 V power connectors (JPMW1–JPMW7, JPMW9) and two 6-pin
power connectors (JPWR1/JPWR2) on the motherboard. Failure in doing so may void the
manufacturer warranty on your power supply and motherboard.
It is strongly recommended that you use a high quality power supply that meets ATX power
supply Specification 2.02 or above. It must also be SSI compliant.
4-Pin Backplane/GPU Power Connectors (JPMW1–JPMW3)
Three 4-pin +12 V power supply connectors (PMW1–JPMW3) are used to provide power to
backplane and GPU devices via cables.
For a detailed diagram of the X14DBT-FAP/-FLAP motherboard, see the layout under "Quick
Reference" on page 12.
49
X14DBT-FAP/-FLAP: Component Installation
