Connector Description
JIPMB1 4-pin BMC External I²C Header
JLCS1/JLCS2 Coolant Leakage Sensors
JPBTN1 Power Button
JPCIE1A1 (P2_PE0 0-
7)
MCIO (P2) PCIe 5.0 x8 Connector
JPCIE1B1 (P2_PE0 8-
15)
MCIO (P2) PCIe 5.0 x8 Connector
JPCIE2A1 (P2_PE1
15-8)
MCIO (P2) PCIe 5.0 x8 Connector
JPCIE3 (P1_PE3 7-0) PCIe 5.0 x8 Connector for M.2 Riser Card
JPCIE4 (P1_PE0 0-15) PCIe 5.0 x16 Connector for AOC
JPMW1–JPMW3 Three 4-pin +12 V Power Connectors
JPRG1
Programming Header for Motherboard Complex Programmable Logic
Devices (CPLD)
JPWR1 Power Connector
JNSCI1 Network Controller Sideband Interface (NC-SI) connector
JRIO1 I/O Module Connector
JRK1 Intel VROC RAID Key Header
JRU1 UID LED and System_Reset Button Select Jumper
JTPM1 Trusted Platform Module/Port 80 connector
JUSB1 (USB0/1 (3.0)) USB Header
JVGA1 VGA port
JVRM1 VRM Header
Note: For detailed instructions on how to configure VROC RAID settings, refer to the VROC
RAID Configuration User's Guide posted on the web page under the following link:
https://www.supermicro.com/support/manuals.
