Chapter 4: Motherboard Connections

IPMI Shared LAN

Set the jumper JBM1 to congure the IPMI shared access on LAN1. The default setting is

Enabled.

IPMI Shared LAN

Jumper Settings

Jumper Setting Denition

Pins 1-2 Open Enabled (Default)

Pins 1-2 Closed Disabled

LAN Swap Commands

To swap the dedicated LAN, please use the below commands.

To read the current mode: 0x30 0x70 0x4 0x0

This will return the GPIO S4 mode:

0: Fiber

1: UTP

To set the mode to Fiber (default): 0x30 0x70 0x4 0x1 0x0

This sets GPIO S4 to low, which defaults to Fiber.

To set the mode to UTP: 0x30 0x70 0x4 0x1 0x1

This sets GPIO S4 to high enabling UTP.

By default, the system is congured for the switch module installed at the back(Fiber).You

can run these commands using IPMItool or IPMICFG. For more information on IPMICFG,

please refer to the following link for the download: https://www.supermicro.com/en/support/

resources/downloadcenter/smsdownload?category=IPMI

Example: smcipmitool

smcipmitool (IP) (user) (password)

smcipmitool 10.134.4.126 ADMIN ADMIN ipmi raw 30 70 4 0 Read status

smcipmitool 10.134.4.126 ADMIN ADMIN ipmi raw 30 70 4 1 0 Set Rear Dedicated LAN

smcipmitool 10.134.4.126 ADMIN ADMIN ipmi raw 30 70 4 1 1 Set Front Dedicated LAN

Example: IPMICFG

IPMICFG raw 0x30 0x70 0x4 0x0 Read status

IPMICFG raw 0x30 0x70 0x4 0x1 0x0 Set Rear Dedicated LAN

IPMICFG raw 0x30 0x70 0x4 0x1 0x1 Set Front Dedicated LAN
