Appendix A BIOS POST Codes

BIOS POST Messages

BIOS Message Description

Previous boot incomplete -

Default conguration used

Previous POST did not complete successfully. POST loads default values

and o󰀨ers to run Setup. If the failure was caused by incorrect values and

they are not corrected, the next boot will likely fail. On systems with control of

wait states, improper Setup settings can also terminate POST and cause this

error on the next boot. Run Setup and verify that the waitstate conguration is

correct. This error is cleared the next time the system is booted.

Memory Size found by POST

di󰀨ered from CMOS

Memory size found by POST di󰀨ered from CMOS.

Diskette drive A error

Diskette drive B error

Drive A: or B: is present but fails the BIOS POST diskette tests. Check to see

that the drive is dened with the proper diskette type in Setup and that the

diskette drive is attached correctly.

Incorrect Drive A type - run

SETUP

Type of oppy drive A: not correctly identied in Setup.

Incorrect Drive B type - run

SETUP

Type of oppy drive B: not correctly identied in Setup.

System cache error - Cache

disabled

RAM cache failed and BIOS disabled the cache. On older boards, check

the cache jumpers. You may have to replace the cache. See your dealer. A

disabled cache slows system performance considerably.

CPU ID: CPU socket number for Multi-Processor error.

EISA CMOS not writeable ServerBIOS2 test error: Cannot write to EISA CMOS.

DMA Test Failed

ServerBIOS2 test error: Cannot write to extended DMA (Direct Memory

Access) registers.

Software NMI Failed

ServerBIOS2 test error: Cannot generate software NMI (Non-Maskable

Interrupt).

Fail-Safe Timer NMI Failed ServerBIOS2 test error: Fail-Safe Timer takes too long.

device Address Conict Address conict for specied device.

Allocation Error for: device

Run ISA or EISA Conguration Utility to resolve resource conict for the

specied device.

CD ROM Drive CD ROM Drive identied.

Entering SETUP... Starting Setup program

Failing Bits: nnnn

The hex number nnnn is a map of the bits at the RAM address which failed the

memory test. Each 1 (one) in the map indicates a failed bit. See errors 230,

231, or 232 above for o󰀨set address of the failure in System, Extended, or

Shadow memory.

Fixed Disk n Fixed disk n (0-3) identied.

Invalid System Conguration

Data

Problem with NVRAM (CMOS) data.

I/O device IRQ conict I/O device IRQ conict error.

PS/2 Mouse Boot Summary

Screen:

PS/2 Mouse installed.
