49

Chapter 4 Motherboard Connections

RAID Key Header

A VROC RAID Key header is located at JRK1. It supports VMD used in creating optional

advanced NVMe RAID congurations. See the VROC appendix for details.

RAID Key Header

Pin Denitions

Pin# Denition

1 Ground

2 3.3V Standby

3 Ground

4 PCH_RAID_KEY

I-SATA 3.0 Port (for SBI-420P-1T3N)

The motherboard has one SATA 3.0 port (I-SATA1), which is supported by the Intel C621A

PCH. Connect this port to the AOM-SB1-SATA31 add-on module.

HDD2 SATA Activity LED Connector (for SBI-420P-1T3N)

JLED is a 3-pin connector used to indicate the status of HDD2 SATA Activity. Connect JLED

to the AOM-SB1-SATA31 add-on module to show HDD2 SATA activity.
