Figure 2-8. Installing into the Rail Frame
3. Lift up the rail frame until it securely rests in an upright position. Then remove the cover
cap from the socket below. Grip the two lift tabs marked "Remove" at the middle of the
cap and pull vertically upwards to remove the cover cap.
Important: The exposed socket contacts are extremely vulnerable and can be
damaged easily. Do not touch or drop objects onto the contacts and be careful
removing the cover cap and when placing the rail frame over the socket.
Figure 2-9. Removing the Cover Cap
27
H14SST-GE: Component Installation
